Remove the pickup roller assembly
1. Remove four screws (callout 1) and the lower stay part (callout 2).
Figure 1-6 Remove the pickup roller assembly (1 of 2)
2
1
2. Release two tabs (callout 1) and remove the pickup roller (callout 2).
Figure 1-7 Remove the pickup roller assembly (2 of 2)
2
1
