7. Remove four screws (callout 1).
Figure 1-60 Remove the low-voltage power supply assembly (4 of 6)
1
8. Remove three screws (callout 1).
9. Disconnect one connector (callout 2) and pull out the low-voltage power supply assembly
(callout 3).
Figure 1-61 Remove the low voltage power supply assembly (5 of 6)
1
2 3
ENWW
Removal and replacement procedures
51
