Top cover
1. Remove the following components:
●
Right cover. See
Right cover on page 10.
●
Left cover. See
Left cover on page 13.
●
Control-panel module. See
Control-panel module on page 19.
●
Rear-side cover. See
Rear-side cover on page 21.
●
Rear-upper cover. See
Rear-upper cover on page 22.
2. Partially open the front door.
3. Remove one screw (callout 1).
Figure 1-38 Remove the top cover (1 of 4)
ENWW Removal and replacement procedures 25
