5. Remove the fuser.
CAUTION: Handle the fuser carefully. The sensors that are mounted to the output side of the
fuser can be easily dislodged. When the fuser is reinstalled, make sure that the sensors are
present, and correctly fastened to the fuser assembly.
Figure 1-88 Remove the fuser (4 of 4)
58 Chapter 1 Removal and replacement ENWW
