3. Disconnect five wire-harness connectors (callout 3). Remove the wire harness from the guides
and one retainer.
Figure 1-86 Remove the fuser (2 of 4)
3
3
4. Remove four screws (callout 4).
Figure 1-87 Remove the fuser (3 of 4)
4
ENWW Removal and replacement procedures 57
