HP LP3065 Specification

Certification and
Compliance
Australian ACA Approval, Canadian Requirements/CSA, CE Marking,
China CCIB/CCEE Approval, CISPR Requirements, Eastern European
Approvals, FCC Approval, German Ergonomic (TUV and GS Mark), ISO
13406-2 Pixel Defect Guidelines, Mexican NOM Approval, MIC
Requirements (New Zealand), Nordic Approvals (Nemko, Fimko, Demko,
Semko), S. Korean MIC Approval, Taiwan BSMI Approval, TCO 99
(emissions, ergonomics, environment), TUV-Ergo, UL Listed, VCCI
Approvals, Windows Vista® Premium Certification
Compatibility Compatible with platforms using the VESA standard video modes. Recommended for use with HP
products.
Service and Warranty Three years parts, labor, and on-site service. 24-hour, 90-day, toll-free technical support.
Replacement options may include second business day on-site service, or next business day
direct replacement, at HP's sole discretion.
3
With direct replacement, HP will ship a replacement
display product directly to you. Using the prepaid shipping labels provided, return your failed
display to HP in the same packaging as the replacement. Certain restrictions and exclusions
apply. For details see your product warranty or contact HP Customer Support.
1
All performance specifications represent the typical specifications provided by HP's component manufacturers; actual
performance may vary either higher or lower.
2
This is the only resolution supported by the monitor. Windows PC and graphics card that supports DVI ports with dual-
link digital bandwidth and VESA DDC standard for plug-and-play setup requires a DVI-D dual-link graphic card that
supports WQXGA (2560 x 1600) resolution.
3
Service levels and response times for HP Care Pack Services may vary depending on your geographic location. Service
starts from date of hardware purchase. Restrictions and limitations apply. HP Care Pack Services extend service contracts
beyond the standard warranties. To choose the right level of service for your HP product, use the HP Care Pack Services
Lookup Tool at: www.hp.com/go/lookuptool . Additional HP Care Pack Services information by product is available at:
www.hp.com/hps/carepack .
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Technical Specifications
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 6

HP LP3065 Specifications

General

Pixel pitch	0.250 mm
Response time	6 ms
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display scanning frequency	Horizontal frequency: 100 kHz, Vertical frequency: 60 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1600 (WQXGA)
UNSPSC-code	43211902
On/off switch	Yes
Audio included	No audio includedNo audio included at platform level
Security features	Kensington Lock-ready
Weight (imperial)	Unpacked30.6 lb lbs
Power requirements	Auto-Sensing, 100 to 240 VAC, 50 +/-3 Hz to 60 +/-3 Hz)
Display resolution at frequency	2560 x 1600 @ 60 Hz (native)
Dimensions (W x D x H) (imperial)	27.2 x 3.3 x 17.9 \
Product dimensions (with stand, imperial)	27.2 x 9.5 x 23.2 \
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 85 %
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	118 W
Certification	Australian ACA Approval, Canadian Requirements/CSA, CE Marking, China CCIB/CCEE Approval, CISPR Requirements, Eastern European Approvals, FCC Approval, German Ergonomic (TUV and GS Mark), ISO 9241-3, 7, 8 VDT Guidelines, ISO 13406-2 Pixel Defect Guidelines, Mexican NOM Approval, MIC Requirements (New Zealand), MPR-II Compliant, Nordic Approvals (Nemko, Fimko, Demko, Semko), S. Korean MIC Approval, Taiwan BSMI Approval, TCO 99 (emissions, ergonomics, environment), TUV-Ergo, UL Listed, VCCI Approvals, Microsoft Windows Certification (Microsoft Windows 98, Microsoft Windows 2000, and Microsoft Windows XP)
Product color	Black
Country of origin	China
I/O ports	One upstream, four downstream USB 2.0 Hub ports (cable included)
USB hub version	2.0
DVI-D ports quantity	3
DVI-I ports quantity	0
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4

Weight and Dimensions

Depth (with stand)	240 mm
Height (with stand)	590 mm
Weight (with stand)	13400 g
Depth (without stand)	84 mm
Width (without stand)	692 mm
Height (without stand)	455 mm
