HP LP3065 Specification

1. Release/locking 1. Four 100 mm VESA mount screw
holes
1. Locking pin screw
2. Four 100 mm VESA mount screw
holes
2. Locking pin hole on release/locking
arm
3. Mounting holes for attachment to
back of HP LP1965, LP2065, and HP
LP2465 monitor stands
Introduction
The HP Quick Release, which ships standard with the HP LP3065 30-inch Widescreen LCD Monitor, is an easy to use, 100
mm VESA-compliant, flat panel monitor mounting solution that allows you to quickly and securely attach a flat panel monitor
to a variety of stands, brackets, arms or wall mounts. HP Quick Release can also be used for mounting any combination of
devices that are compatible with the 100 mm VESA Flat Display Mounting Interface Standard. The failsafe "Sure-Lock"
mechanism snaps the monitor (or mounted device) securely in place, and can be further secured with a theft-deterrent
security screw.
Uniquely flexible product configurations
HP Quick Release enables uniquely flexible product configuration alternatives in a variety of settings, such as:
Storefronts/kiosks: Mount flat panel monitors for easy viewing and add touchscreens for interactivity.
Trade shows: Securely mount LCD TVs or monitors in common areas and quickly remove them for safekeeping at the
end of the day.
Front office environments: Minimize desk space requirements with wall or swing-arm mounting of monitors in
reception areas.
Training labs: Mount a monitor directly on a 100 mm VESA-compatible PC or an HP Thin Client for all-in-one
convenience.
Medical/institutional settings: Securely mount monitors in nursing stations and public areas.
Conference rooms: Mount projectors (with 100 mm VESA-compliant pre-drilled holes) on ceilings, and monitors on
walls or tables.
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Overview - HP LCD Monitor Quick Release (included)
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 7

HP LP3065 Specifications

General

Pixel pitch	0.250 mm
Response time	6 ms
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display scanning frequency	Horizontal frequency: 100 kHz, Vertical frequency: 60 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1600 (WQXGA)
UNSPSC-code	43211902
On/off switch	Yes
Audio included	No audio includedNo audio included at platform level
Security features	Kensington Lock-ready
Weight (imperial)	Unpacked30.6 lb lbs
Power requirements	Auto-Sensing, 100 to 240 VAC, 50 +/-3 Hz to 60 +/-3 Hz)
Display resolution at frequency	2560 x 1600 @ 60 Hz (native)
Dimensions (W x D x H) (imperial)	27.2 x 3.3 x 17.9 \
Product dimensions (with stand, imperial)	27.2 x 9.5 x 23.2 \
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 85 %
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	118 W
Certification	Australian ACA Approval, Canadian Requirements/CSA, CE Marking, China CCIB/CCEE Approval, CISPR Requirements, Eastern European Approvals, FCC Approval, German Ergonomic (TUV and GS Mark), ISO 9241-3, 7, 8 VDT Guidelines, ISO 13406-2 Pixel Defect Guidelines, Mexican NOM Approval, MIC Requirements (New Zealand), MPR-II Compliant, Nordic Approvals (Nemko, Fimko, Demko, Semko), S. Korean MIC Approval, Taiwan BSMI Approval, TCO 99 (emissions, ergonomics, environment), TUV-Ergo, UL Listed, VCCI Approvals, Microsoft Windows Certification (Microsoft Windows 98, Microsoft Windows 2000, and Microsoft Windows XP)
Product color	Black
Country of origin	China
I/O ports	One upstream, four downstream USB 2.0 Hub ports (cable included)
USB hub version	2.0
DVI-D ports quantity	3
DVI-I ports quantity	0
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4

Weight and Dimensions

Depth (with stand)	240 mm
Height (with stand)	590 mm
Weight (with stand)	13400 g
Depth (without stand)	84 mm
Width (without stand)	692 mm
Height (without stand)	455 mm
