HP LP3065 Specification

Mechanical Dimensions
(H x W x D)
Packaged 7.8 x 6.25 x 1.5 in (19.8 x 15.9 x 3.8 cm)
Unpackaged 6.3 x 5.2 x 0.65 in (16 x 13.2 x 1.65 cm)
Weight Packaged 1.1 lb (0.49 kg)
Unpackaged 0.82 lb (0.37 kg)
Additional
components
Eight 10 mm mounting screws (for attachment to VESA compliant monitor mounts)
Eight 15.5 mm mounting screws (for attachment to HP Thin Client products)
Four 20 mm mounting screws (for attachment to back of select HP flat panel monitor
stands)
One Quick Release "locking" screw
Color Carbonite
Notes No HP monitors allow positioning of a thin client product between a monitor screen and its
stand.
1.
The Quick Release device is not to be used between a monitor screen and its stand unless
provided that way from the factory.
2.
Under no circumstances is the Quick Release device intended to be used in an orientation
where the Release/Lock lever is oriented downward.
3.
Supported weight
capacity
The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg)
depending upon the mounting configuration used. Please note this is a total weight limit for all
devices mounted, i.e. the combined weight of the monitor and a second device such as an HP
Thin Client cannot exceed 24 pounds. Because mounting surfaces vary widely and the final
mounting method and configuration may vary, mounting fasteners are not supplied (other than
the VESA-compliant screws). HP recommends that you consult with a qualified engineering,
architectural or construction professional to determine the appropriate type and quantity of
mounting fasteners required for your application and to ensure that your mounting solution is
properly installed to support applied loads.
© Copyright 2008 Hewlett-Packard Development Company, L.P.
Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other
countries.
HP shall not be liable for technical or editorial errors or omissions contained herein. The information is provided as is
without warranty of any kind and is subject to change without notice. The warranties for HP products are set forth in the
express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an
additional warranty. All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Technical Specifications - HP LCD Monitor Quick Release (included)
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 8

HP LP3065 Specifications

General

Pixel pitch	0.250 mm
Response time	6 ms
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display scanning frequency	Horizontal frequency: 100 kHz, Vertical frequency: 60 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1600 (WQXGA)
UNSPSC-code	43211902
On/off switch	Yes
Audio included	No audio includedNo audio included at platform level
Security features	Kensington Lock-ready
Weight (imperial)	Unpacked30.6 lb lbs
Power requirements	Auto-Sensing, 100 to 240 VAC, 50 +/-3 Hz to 60 +/-3 Hz)
Display resolution at frequency	2560 x 1600 @ 60 Hz (native)
Dimensions (W x D x H) (imperial)	27.2 x 3.3 x 17.9 \
Product dimensions (with stand, imperial)	27.2 x 9.5 x 23.2 \
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 85 %
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	118 W
Certification	Australian ACA Approval, Canadian Requirements/CSA, CE Marking, China CCIB/CCEE Approval, CISPR Requirements, Eastern European Approvals, FCC Approval, German Ergonomic (TUV and GS Mark), ISO 9241-3, 7, 8 VDT Guidelines, ISO 13406-2 Pixel Defect Guidelines, Mexican NOM Approval, MIC Requirements (New Zealand), MPR-II Compliant, Nordic Approvals (Nemko, Fimko, Demko, Semko), S. Korean MIC Approval, Taiwan BSMI Approval, TCO 99 (emissions, ergonomics, environment), TUV-Ergo, UL Listed, VCCI Approvals, Microsoft Windows Certification (Microsoft Windows 98, Microsoft Windows 2000, and Microsoft Windows XP)
Product color	Black
Country of origin	China
I/O ports	One upstream, four downstream USB 2.0 Hub ports (cable included)
USB hub version	2.0
DVI-D ports quantity	3
DVI-I ports quantity	0
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4

Weight and Dimensions

Depth (with stand)	240 mm
Height (with stand)	590 mm
Weight (with stand)	13400 g
Depth (without stand)	84 mm
Width (without stand)	692 mm
Height (without stand)	455 mm
