3. Starting at the rear vertical edge, release four tabs (callout 1) and remove the left cover.
Figure 1-7 Remove the left cover (2 of 3)
1
1
NOTE: Before proceeding, take note of the locations of the tabs (callout 1) on the back side of the
cover. When reinstalling the left cover, align the all of the tabs with the slots.
Figure 1-8 Remove the left cover (3 of 3)
1
ENWW Removal and replacement procedures 13
