Install a replacement engine controller assembly
Release one tab (callout 1), remove the guide (callout 2) from the discarded engine controller assembly
(callout 3), and then install the guide on the replacement assembly.
Figure 1-72 Install a replacement engine controller assembly
3
1
2
ENWW Removal and replacement procedures 53
