11. Unhook the catching part of the ITB fixing spring (callout 1) and turn the spring (callout 2) toward the
front side.
Figure 1-97 Remove the ITB assembly (13 of 17)
1
2
Figure 1-98 Remove the ITB assembly (14 of 17)
2
ENWW Removal and replacement procedures 69
