6–42 Maintenance and Service Guide

Removal and Replacement Procedures

4. Turn the notebook top-side up with the front toward you.

5. Release the ZIF connector to which the TouchPad cable 1 is

connected and disconnect the TouchPad cable from the

system board.

6. Disconnect the fingerprint reader cable 2 from the

system board.

7. Remove the Torx T8M2.5×7.0 screw 3 that secures the

top cover to the notebook.

Disconnecting the Top Cover Cables and Removing the

Top Cover Screw
