6–50 Maintenance and Service Guide
Removal and Replacement Procedures
6.22 System Board
✎
When replacing the system board, ensure that the following
components are removed from the defective system board and
installed on the replacement system board:
■ Memory modules (Section 6.7)
■ Processor (Section 6.14)
■ Mini PCI communications module (Section 6.16)
■ RTC battery (Section 6.20)
■ PC Card assembly (Section 6.20)
1. Prepare the notebook for disassembly (Section 6.3),
and then remove the following components:
a. Hard drive (Section 6.4)
b. Bluetooth board (Section 6.6)
c. Optical drive (Section 6.8)
d. Switch cover (Section 6.9)
e. Keyboard (Section 6.11)
f. Fan (Section 6.12)
g. Heat sink (Section 6.13)
h. Button board (Section 6.15)
i. Display assembly (Section 6.17)
j. Top cover (Section 6.18)
k. Speaker (Section 6.21)
System Board Spare Part Number Information
For use on HP Compaq nx6125 models
For use on HP Compaq nx6115 models
393569-001
393570-001
