HP Officejet Pro X451dn - Page 10

2. Remove two screws (callout 1) from the front of the product.
Figure 1-70 Remove the right cross brace (1 of 4)
1
3. Remove two screws (callout 1) from the rear of the product.
Figure 1-71 Remove the right cross brace (2 of 4)
1
