HP Officejet Pro X451dn - Plate console left

4. Remove the brace.
Figure 1-72 Remove the right cross brace (3 of 4)
Figure 1-73 Remove the right cross brace (4 of 4)
Plate console left
1. Remove the following components:
●
Rear cover.
●
Left door.
●
Left rear cover.
ENWW
Removal and replacement procedures
45
