Item Description Spare part number
(1) Display panel, 20-inch, non-glare 646794-001
(2) Display bezel 651599-001
Memory modules (PC3-10600, 1333-MHz; not illustrated)
2-GB 651609-001
1-GB 651608-001
(3) Heat sink assembly (thermal module) (includes replacement thermal material) 651607-001
(4) Fan 651606-001
(5) Power button board 651585-001
(6) System board 648965-001
Thermal pads (installed under system board; not illustrated)
DIMM thermal pad (20mm x 50mm x 2.5mm) 651595-001
VRM thermal pad (15mm x 40mm x 4mm) 651596-001
(7) WLAN module (802.11b/g/n) (1x1 mini card) 634906-001
(8) Inverter board 651601-001
(9) Webcam module 651586-001
(10) Speakers
Right speaker 651597-001
Left speaker 651598-001
(11) WLAN antenna cable 651594-001
(12) Inverter cable 651588-001
(13) Optical drive cable 651590-001
(14) LVDS cable 651589-001
(15) Webcam cable 651591-001
(16) Hard drive cable 651592-001
(17) Power button/LED cable 651593-001
Processor (includes replacement thermal material; not illustrated))
Intel Core2 Duo processors
●
E8500 (3.16-GHz, 6-MB L2 cache, 1333-MHz FSB) 466170-001
●
E8400 (3.00-GHz, 6-MB L2 cache, 1333-MHz FSB) 509554-001
●
E7600 (3.06-GHz, 3-MB L2 cache, 1066-MHz FSB) 573954-001
●
E7500 (2.93-GHz, 3-MB L2 cache, 1066-MHz FSB) 586745-001
Intel Pentium processors
24 Chapter 6 Illustrated parts catalog
