7.
Open both latches of the memory module socket (1), and remove the memory module from the
socket (2).
Figure 7-10 Removing the memory module
NOTE: If you are removing both cards, you must remove the upper one before removing the
lower one.
To install a memory module, reverse the removal procedures.
38 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
