2. Pull out the Tray 1 extension.
3. Open the paper guides completely, and then load the paper stack into Tray 1.
4. Close the paper guides against the loaded media.
Load Tray 2
Tray 2 is the default (main) paper tray at the front of the product.
NOTE: If you are not using Alternate Letterhead Mode (ALM), place the paper with the side to be printed on
face-up, with the top edge toward the left side of the tray. For ALM orientation, see Load letterhead or
preprinted forms.
1. Pull the tray out of the product.
44 Chapter 4 Paper and print media ENWW
