Display assembly subcomponents
Item Component Spare part number
(1) Display bezel 697907-001
(2) Display Hinge Kit (includes left and right display hinges and brackets) 697908-001
(3) 35.6 cm (14.0 in), HD, WLED, SVA BrightView flat display panel 698523-001
(4) Webcam/microphone module 697903-001
(5) Antenna Kit (includes left and right wireless antenna cables and transceivers) 697913-001
(6) Display Panel Cable Kit (includes display panel cable and webcam/microphone
module cable)
697911-001
(7) Back cover:
● Ruby red 697909-001
●
Silver 704381-001
●
Sparkling black 697910-001
22 Chapter 3 Illustrated parts catalog
