Description Spare part number
●
For Windows 8 Standard 718726-501
●
For Ubuntu Linux or FreeDOS 1.0 718726-001
For use with computer models with Intel HM77 chipsets and i3-3217U processors:
●
For Windows 8 Standard 698492-501
●
For Ubuntu Linux or FreeDOS 1.0 698492-001
For use with computer models with Intel HM77 chipsets and i3-2375M processors:
●
For Windows 8 Standard 718917-501
●
For Ubuntu Linux or FreeDOS 1.0 718917-001
System boards supporting UMA graphics and AMD processors
For use with computer models with AMD A70M chipsets and A6-4455M processors:
●
For Windows 8 Standard 703858-501
● For Ubuntu Linux or FreeDOS 2.0 703858-001
For use with computer models with AMD A70M chipsets and A4-4355M processors:
●
For Windows 8 Standard 703857-501
● For Ubuntu Linux or FreeDOS 2.0 703857-001
For use with computer models with AMD A68M chipsets and E2-2000 processors:
●
For Windows 8 Standard 703856-501
● For Ubuntu Linux or FreeDOS 2.0 703856-001
For use with computer models with AMD A68M chipsets and E2-1800 processors:
●
For Windows 8 Standard 699812-501
● For Ubuntu Linux or FreeDOS 2.0 699812-001
For use with computer models with AMD A68M chipsets and E1-1500 processors:
●
For Windows 8 Standard 703855-501
● For Ubuntu Linux or FreeDOS 2.0 703855-001
For use with computer models with UMA graphics, AMD A68M chipsets, E1-1200 processors:
●
For Windows 8 Standard 699811-501
● For Ubuntu Linux or FreeDOS 2.0 699811-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
Before removing the system board, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
54 Chapter 4 Removal and replacement procedures
