EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Size (if
applicable)
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Quick release Base stand
2. Strip the screws from rear cover so that the rear metal cover can be removed , after be turn back;
3. Strip the five screws from panel holder
4. Push up and disassemble the cover from the panel
5. To remove the shielding(contain the other material )
6. Strip the screws
7. Release all materials and put some by ESD
3.2 Optional : Depending upon the complexity of the disassembly process, a graphic depicting the locations of items contained within
the product which require selective treatment (with descriptions and arrows identifying locations) can be inserted below:
