RTC battery
Description Spare part number
RTC battery 449137-001
Before removing the RTC battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 41).
5. Hard drive cover (see
Hard drive on page 53).
Remove the RTC battery:
1. Turn the system board upside down.
2. Release the RTC battery from the clips on the system board (1).
3. Remove the RTC battery (2).
Reverse this procedure to install the RTC battery.
Component replacement procedures
45
