Item Description Spare part number

(10) Modem module

NOTE: The modem module spare part kit does not include a modem module cable. The modem module cable is

included in the Cable Kit, spare part number 516328-001.

For use in all countries and regions except Australia and New Zealand 461749-001

For use only in Australia and New Zealand 461749-011

(11) System board (includes replacement thermal material)

With ATI Mobility Radeon HD 4650 discrete graphics subsystem and 1-GB of dedicated

memory

516294-001

With ATI Mobility Radeon HD 4650 discrete graphics subsystem and 1-GB of dedicated

memory

516293-001

With ATI Mobility Radeon HD 4530 discrete graphics subsystem and 512-MB of

dedicated memory

516292-001

With Intel GMA 4700MHD UMA graphics subsystem and shared memory 516291-001

System board bracket (not illustrated) 516334-001

(12) Processor (includes replacement thermal material)

Intel Core™2 Quad Q9100 2.26-GHz with 12-MB L2 cache and 1066-MHz FSB 507947-001

Intel Core2 Quad Q9000 2.00-GHz with 12-MB L2 cache and 1066-MHz FSB 507948-001

Intel Core2 Duo T9800 2.93-GHz with 6-MB L2 cache and 1066-MHz FSB 507951-001

Intel Core2 Duo T9550 2.66-GHz with 6-MB L2 cache and 1066-MHz FSB 507953-001

Intel Core2 Duo P8700 2.53-GHz with 3-MB L2 cache and 1066-MHz FSB 507960-001

Intel Core2 Duo P8600 2.40-GHz with 3-MB L2 cache and 1066-MHz FSB 507963-001

Intel Core2 Duo P7450 2.13-GHz with 3-MB L2 cache and 1066-MHz FSB 507965-001

Intel Core2 Duo T6600 2.20-GHz with 2-MB L2 cache and 800-MHz FSB 513593-001

Intel Core2 Duo T6400 2.00-GHz with 2-MB L2 cache and 800-MHz FSB 513592-001

Intel Pentium Dual Core T4200 2.00-GHz with 1-MB L2 cache and 800-MHz FSB 513599-001

(13) ExpressCard module 516324-001

Fan/heat sink assembly (includes replacement thermal material)

(14)

For use only with computer models equipped with graphics subsystems with discrete

memory

516876-001

(15) For use only with computer models equipped with graphics subsystems with UMA

memory

516331-001

Optical drive bracket (not illustrated)

For use in computers with discrete graphics subsystems 519481-001

For use in computers with UMA graphics subsystems 535085-001

(16) Audio/infrared board (includes cable)

For use in computers with discrete graphics subsystems 516330-001

For use in computers with UMA graphics subsystems 518166-001

20 Chapter 3 Illustrated parts catalog
