HP PAVILION DV7 User Manual

Spare part
number
Description
516357-A41 Keyboard for use in white computers in Belgium
516357-AD1 Keyboard for use in white computers in South Korea
516357-B31 Keyboard for use white computers internationally
516357-BB1 Keyboard for use in white computers in Israel
516357-DH1 Keyboard for use in white computers in Denmark, Norway, and Sweden
516357-DJ1 Keyboard for use in white computers in Greece
516360-001 Top cover for use only with white computer models not equipped with a fingerprint reader
516443-001 Display enclosure for use in white computers with flush glass displays (includes wireless antenna
transceivers and cables and logo LED board and cable)
516444-001 Display Hinge Kit for use in computers with flush glass displays
516876-001 Fan/heat sink assembly for use in computers with discrete graphics subsystems
517638-001 Bluetooth module cable
517639-001 Hard Drive Hardware Kit (includes left and right bracket rails, connector cable, Mylar cover with tab, and
4 rubber isolators)
518162-001 Primary hard drive cover
518164-001 Secondary hard drive cover
518165-001 Power button board for use in computers with UMA graphics subsystems
518166-001 Audio/infrared board for use in computers with UMA graphics subsystems (includes cable)
518168-001 USB board for use in computers with UMA graphics subsystems (includes cable)
519259-001 17.3-inch HD+ BrightView display assembly for use in black computers
519260-001 17.3-inch HD+ flush glass AntiGlare display assembly for use in black computers
519261-001 Display enclosure for use in black computers with BrightView displays (includes wireless antenna
transceivers and cables and logo LED board and cable
519262-001 Display enclosure for use in black computers with flush glass displays (includes wireless antenna
transceivers and cables and logo LED board and cable)
519265-001 Black molded keyboard for use in the United States
519265-031 Black molded keyboard for use in the United Kingdom
519265-041 Black molded keyboard for use in Germany
519265-051 Black molded keyboard for use in France
519265-061 Black molded keyboard for use in Italy
519265-071 Black molded keyboard for use in Spain
519265-111 Black molded keyboard for use in Switzerland
519265-131 Black molded keyboard for use in Portugal
519265-141 Black molded keyboard for use in Turkey
519265-211 Black molded keyboard for use in Hungary
Sequential part number listing 33

HP PAVILION DV7 Specifications

General

LED backlight	Yes
Display surface	Gloss
Display diagonal	17.3 \
Display brightness	200 cd/m²
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3210M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.5 GHz
Processor cache type	L3
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM77 Express
Memory slots	2x SO-DIMM
Internal memory	6 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 2 + 1 x 4 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	1000 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Number of SSDs installed	0
On-board graphics card ID	0x166
Discrete graphics card model	NVIDIA® GeForce® GT 630M
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	Beats Audio
Video capturing speed	30 fps
Front camera resolution	1280 x 720 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Keyboard layout	-
Pointing device	Touchpad
Operating system installed	Windows 7 Home Premium
Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Battery capacity	2800 mAh
Battery life (max)	- h
Number of battery cells	6
AC adapter power	90 W
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Processor code	SR0N0
Processor ARK ID	65708
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	274 mm
Width	416 mm
Height	35.2 mm
Weight	3150 g
