537488-001 — Removing and Replacing a Hard Disk Drive 9
9 Insert and tighten the two screws that secure the cage
in the computer.
10 Set the computer upright.
11 Hold the front panel over the front of the computer,
and then press the left side of the front panel, inserting
the tabs into the computer holes. Swing the right side
of the panel toward the computer, inserting the panel
tabs, and then press it into the computer.
12 Hold the side panel over the side of the computer with
the front edge of the panel about 2.5 cm (1 inch) from
the front of the computer.
