Plastics Kit
Item Description Spare part number
Plastics Kit 487926-001
(1) ExpressCard slot bezel
(2) Hard drive cover (includes 1 rubber foot and 2 captive screws, secured by C-clips)
(3) Display connector cover (includes 1 captive screw, secured by a C-clip)
(4) WLAN module compartment cover (includes 1 captive screw, secured by a C-clip)
(5) Memory module compartment cover (includes 2 captive screws, secured by C-clips)
22 Chapter 3 Illustrated parts catalog
