7 Screw listing
This section provides specification and reference information for the screws and screw locks used in
the computer. All screws and screw locks listed in this section are available in the Screw Kit, spare
part number 464116-001.
Phillips PM3.0×3.0 screw
Color Quantity Length Thread Head width
Silver 4 3.0 mm 3.0 mm 5.0 mm
Where used: 4 screws that secure the hard drive bracket to the hard drive
86 Chapter 7 Screw listing
