3–28 Startup Guide
Notebook Features
Component Description
1 Battery bay Holds the battery pack. (Battery type
and shipment mode vary by model.)
2 Exhaust vents Allows airflow to cool internal
components.
Ä
To prevent overheating, do
not obstruct the vent. Do not
allow a hard surface, such as
an adjoining printer, or a soft
surface, such as bedding or
clothing, to block airflow.
3 Hard drive bay Holds the primary hard drive.
4 Memory compartment Contains 2 memory slots, one of which
is accessible for an optional 128-MB,
256-MB, 512-MB, or 1024-MB memory
module upgrade. As shipped, the
memory slot may be filled with
a replaceable memory module, or it
may be vacant, depending on the
notebook model.
5 Battery release latch Releases the battery pack from the
battery bay.
