HP Photo Printer

10 HP Photosmart M-series dock User’s Manual
Transferring Images to a
Computer Using the Dock
1 Confirm the following:
• The dock insert is attached to the top of the dock. (See
step 1 on page 6.)
• The HP AC power adapter is plugged into the dock,
and
the power cord for the power adapter is plugged into an
electrical outlet. (See step 4 on page 7.)
• The USB cable is connected between the dock and your
computer. (See step 4 on page 7.)
• The camera is inserted into the dock. (See step 5 on
page 8.)
• The HP Image Zone software is installed on your
computer. (See your camera User’s Manual.)
• If you are using a Macintosh computer, the camera’s USB
Configuration is set to Disk Drive in the Setup menu. (See
your camera User’s Manual.)
# Name Description
3
TV button
Activates the TV connection. If the light above this
button is:
z On—The dock is connected to the TV.
z Blinking—An audio/video signal is being sent to
the TV.
z Off—The dock is not connected to the TV.
