HP Photosmart 2570

4 • HP All-in-One
11
12
Insert the tri-color print cartridge
a Hold the tri-color print cartridge with the HP label facing
up.
b Place the tri-color print cartridge in front of the left slot
marked with the green label.
c Push the cartridge fi rmly into the slot until it snaps into
place.
a Hold the black print cartridge with the HP label facing up.
b Place the black print cartridge in front of the right slot
marked with the black and orange label.
c Push the cartridge fi rmly into the slot until it snaps into
place.
d Close the access door.
The device must be On before you can insert the print
cartridges.
When the device is on, the print carriage is on the right
side.
Insert the black print cartridge
