HP Photosmart C309a

Label Description
12 Photo light
13 Memory card slot for CompactFlash cards
14 Front USB/PictBridge port for your camera or other storage device
15 Lid backing
16 Lid
17 Glass
18 Cartridge door access handle
19 Paper-width guide for the main input tray
20 Main input tray (also referred to as the input tray)
Figure 3-2 Top and rear views of the printer
Label Description
21 Printhead assembly
22 Cartridge access area
23 Model number location
24 Rear USB port
25 Ethernet port
26 Power connection*
27 1-LINE (fax) and 2-EXT (phone) ports
28 Two-sided printing accessory
* Use only with the power adapter supplied by HP.
Control panel features
The following diagram and related table provide a quick reference to the HP Photosmart
control panel features.
