HP Designjet Printers
Model specifications and schematic
•Shaded rows indicate variations between models.
•See page 143 for complete specifications.
Supplies and accessories
Please see the November 2005 Supplies IRG for complete supplies information (4AA0-0791ENUC).
Ink
•HP 84 Ink Cartridge, black C5016A
•HP 84 Printhead, black C5019A
•HP 84 3-Ink Black Cartridge
Multipack C9430A
•HP 85 Ink Cartridges:
Cyan C9425A
Magenta C9426A
Yellow C9427A
Light Cyan C9428A
Light Magenta C9429A
•HP 85 Printheads:
Cyan C9420A
Magenta C9421A
Yellow C9422A
Light Cyan C9423A
Light Magenta C9424A
•HP 85 3-Ink Multipacks:
Cyan C9431A
Magenta C9432A
Yellow C9433A
Light Cyan C9434A
Light Magenta C9435A
Paper-handling accessories
•Spindle Q1264A
•Roll Feed with Automatic Cutter
(std on 130nr/130gp) Q1247A
Other
•Stand and Bin Q1246A
•EFI Designer Edition 4.2
for HP XL Q6643C
HP Designjet 130 series
(130 shown)
Front view
Note: 130nr and 130gp include automatic
roll feed with automatic cutter and HP Jetdirect
620n LAN card (optional for 130).
Rear view
LCD
OK
Cancel
Power
Paper tray
70-sheet
Ink
cartridge
access
Output
tray
EIO slot
USB port
Parallel port
AC power
130
Product Number C7791C
Media Sizes, Std
Letter, legal, tabloid, executive, C, D,
C+, D+, envelopes, banners
Media Sizes, Custom 3 × 5.6 in to 24.6 × 64 in
Media Width, Max
24.6 in
Print Length, Max
Rolls: 50 ft; sheets: 64 in
Print Technology
HP Color Thermal Inkjet
Color Technology
HP Color Layering Technology,
HP PhotoREt IV
Print Quality, Color Best
2400 × 1200 dpi
Prints Color
Yes
Print Cartridges
6 (1 each black, cyan, magenta,
yellow, light cyan, light magenta)
Print Cartridge Capacity
69 ml (each black, yellow, light cyan,
light magenta), 28 ml (each cyan,
magenta)
Ink Types
Dye-based HP Vivera Inks
Print Languages, Std
HP PCL 3-GUI RGB-24 bit contone
Media Types
Paper (plain, inkjet, coated,
heavyweight coated, semi-gloss,
glossy, proofing, photo,
brochure/flyer), transparencies
Media Handling/
Document Finishing
Sheet feed (70-sheet input tray,
manual single-sheet feed, rear path),
optional roll feed with automatic cutter
Memory, Std
64 MB
Memory, Max
64 MB
Connectivity, Std USB 1.1 (USB 2.0-compliant),
Centronics parallel IEEE-1284
(ECP-compliant), 1 EIO slot
Connectivity, Opt
HP Jetdirect internal and wireless
print servers
Print Speed:
Draft Quality
Normal Quality
Best Quality
Up to 1.2 mpp
(color image on coated paper, D-size)
Up to 5.3 mpp (
color image on coated paper, D-size)
Up to 12.1 mpp
(color image on coated paper, D-size)
Up to 1.2 mpp
(color image on coated paper, D-size)
Up to 5.3 mpp
(color image on coated paper, D-size)
Up to 12.1 mpp
(color image on coated paper, D-size)
HP Jetdirect internal and wireless
print servers
USB 1.1 (USB 2.0-compliant),
Centronics parallel IEEE-1284
(ECP-compliant), 1 EIO slot,
HP Jetdirect 620n LAN card
64 MB
64 MB
Sheet feed (70-sheet input tray,
manual single-sheet feed, rear path),
roll feed with automatic cutter
Paper (plain, inkjet, coated,
heavyweight coated, semi-gloss,
glossy, proofing, photo,
brochure/flyer), transparencies
HP PCL 3-GUI RGB-24 bit contone
Dye-based HP Vivera Inks
69 ml (each black, yellow, light cyan,
light magenta), 28 ml (each cyan,
magenta)
6 (1 each black, cyan, magenta,
yellow, light cyan, light magenta)
Yes
2400 × 1200 dpi
HP Color Layering Technology,
HP PhotoREt IV
HP Color Thermal Inkjet
Rolls: 50 ft; sheets: 64 in
24.6 in
3 × 5.6 in to 24.6 × 64 in,
rolls up to 24-inch wide
Letter, legal, tabloid, executive, C, D,
C+, D+, envelopes, banners
C7791D
130nr
Print Languages, Opt
Adobe PostScript 3 via software RIP Adobe PostScript 3 via software RIP
Paper Trays, Std
11
Adobe PostScript 3 via software RIP
1
Up to 1.2 mpp
(color image on coated paper, D-size)
Up to 5.3 mpp
(color image on coated paper, D-size)
Up to 12.1 mpp
(color image on coated paper, D-size)
HP Jetdirect internal and wireless
print servers
USB 1.1 (USB 2.0-compliant),
Centronics parallel IEEE-1284
(ECP-compliant), 1 EIO slot,
HP Jetdirect 620n LAN card
64 MB
64 MB
Sheet feed (70-sheet input tray,
manual single-sheet feed, rear path),
roll feed with automatic cutter
Paper (plain, inkjet, coated,
heavyweight coated, semi-gloss,
glossy, proofing, photo,
brochure/flyer), transparencies
HP PCL 3-GUI RGB-24 bit contone
Dye-based HP Vivera Inks
69 ml (each black, yellow, light cyan,
light magenta), 28 ml (each cyan,
magenta)
6 (1 each black, cyan, magenta,
yellow, light cyan, light magenta)
Yes
2400 × 1200 dpi
HP Color Layering Technology,
HP PhotoREt IV
HP Color Thermal Inkjet
Rolls: 50 ft; sheets: 64 in
24.6 in
3 × 5.6 in to 24.6 × 64 in,
rolls up to 24-inch wide
Letter, legal, tabloid, executive, C, D,
C+, D+, envelopes, banners
C7791E
130gp
