Installing DIMMs (memory) 99
4 Position the DIMM chip over the slot
located inside the printer memory
door. The gold contacts should be
pointing down and the cutouts
should be on the left side.
5 Carefully press the DIMM chip into
the slot, ensuring it is straight and all
the way down. The cam latches
should rotate inward.
6 Lock the cam latches into place by
pressing the handles towards each
other.
4
5
6
