Clearing printer paper jams 59
5 Gently pull the pickup roller straight
out.
6 Position the new part within the slot
of the old pickup roller.
7 Rotate the bottom of the new pickup
roller towards the back of the printer
until it snaps into place.
8 Use the eraser end of a pencil to
press the spring arm behind the
white cam roller.
WARNING!
Failure to complete this procedure can
cause damage to the printer.
9 Reinstall the toner cartridge and
close the printer door.
Note
Plug the printer in to turn it back on.
5
6
7
9
8
