Board Size
Micro-ATX, PCB Size: 9.6 x 9.6 in (24.38 x 24.38 cm)
4-layer PCB with green color
Additional Features
Bootable without keyboard, mouse or monitor
Keyboard/mouse/USB wake up
Support S3, S4 and S5
ACPI status
Hardware monitor capability
CPU fan speed control
One button reset/recovery
*
*Reset function will be set for China/Hong Kong/Korea; Recovery function will
be set for the other regions
Network Interface
Realtek 8111DL GbE Ethernet Controller
Intel Gigabit CT Desktop NIC
Wireless
MT: Wireless 802.11b/g/n PCIe Card (full height bracket)
SFF: Wireless 802.11b/g/n PCIe Card (low profile bracket)
Modem
LSI PCIe x1 56K International SoftModem
Power Supply
Microtower
Small Form Factor
Model
250W/300W PFC+HV
300W Non-PFC
250W PFC+HV
250W PFC
Standard Efficiency
N/A N/A N/A N/A
Energy Efficient
N/A N/A N/A N/A
Operating Voltage Range
90 to 132VAC, or
180 to 264VAC
90 to 132VAC, or
180 to 264VAC
90 to 132VAC, or
180 to 264VAC
90 to 132VAC, or
180 to 264VAC
Rated Voltage Range
100 to 127VAC, or
200 to 240VAC
100 to 127VAC, or
200 to 240VAC
100 to 127VAC, or
200 to 240VAC
100 to 127VAC, or
200 to 240VAC
Rated Line Frequency
50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
Operating Line Frequency
Range
47 – 63 Hz 47 – 63 Hz 47 – 63 Hz 47 – 63 Hz
Rated Input Current
8A/4A 8A/4A
7A/3.5A
6A/3A
115V/230V Line switch
Yes Yes Yes Yes
Rated Input Current with
Energy Efficient* Power
Supply
N/A N/A N/A N/A
Current Leakage
(NFPA 99)
<3.5mA <3.5mA <3.5mA <3.5mA
System Heat Dissipation
250W:
48.5 W or 165.482
51.8W or 176.7416
BTU/hr.(For 115V/60Hz)
51.9W or 177.0828
BTU/hr. (For 115V/60Hz)
52.8W or 180.1536
BTU/hr. (For 115V/60Hz)
QuickSpecs
HP Pro 3000 Business PC
System Details
DA - 13483 North America — Version 8 — March 7, 2011
Page 11
