Base Unit
MT: Micro ATX Microtower chassis, including power supply and front bezel; five (5) drive bays and
four expansion slots
SFF: Micro ATX Small Form Factor chassis, including power supply and front bezel; three (3) drive
bays and four expansion slots
Active type heatsink
92 x 92 x 25 mm chassis fan for Microtower chassis
No chassis fan for Small Form Factor chassis
System board with Intel G45S Express chipset, Intel I/O Controller Hub 10R (ICH10R), Realtek
RTL8111DL Ethernet controller, Intel GMA X4500HD graphics, and Realtek audio, (1) PCI Express x1
slots, (1) PCI Express x16 slot, (2) PCI, (4) DDR3 DIMM memory slots, (4) Serial ATA data connectors,
(8) USB Ports (see USB support below), (1)VGA, (1)DVI-D port, (1) serial port in the rear IO
Power cord
Slots
PCI
One (1) PCI Express x1 slots on PCA
One (1) PCI Express x16 slot on PCA (for graphic cards)
Two (2) PCI slots on PCA
Memory Expansion
Four (4) DDR3 SDRAM DIMM slots (8 GB maximum memory support)
NOTE:
For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory
may not be available due to system resource requirements. Addressing memory above 4 GB requires a 64-
bit operating system.
Bays
Internal
MT: Two (2) 3.5-inch
SFF: One (1) 3.5-inch
External
MT: Two (2) 5.25-inch; One (1) 3.5-inch
SFF: One (1) 5.25-inch; One (1) 3.5-inch
USB Support
EHCI high-speed USB 2.0 controller
Two (2) front ports; Six (6) rear ports
Six (6) internal ports on system board:
2 for front ports
2 for media card reader
2 reserved for future upgrade
Interfaces
(Legacy)
One (1) PS/2 keyboard port
One (1) PS/2 mouse port
One (1) analog VGA video port
One (1) DVI-D video port
One (1) serial port
One (1) line in; one (1) line out; one (1) microphone in
One (1) RJ45 network port
QuickSpecs
HP Pro 3000 Business PC
System Details
DA - 13483 North America — Version 8 — March 7, 2011
Page 7
