Table 7-4 Expansion Slot Locations (continued)
Item Description
PCI1 PCI slot
PCI2 PCI slot
NOTE: You can install a PCI Express x1, x4, x8, or x16 expansion card in the PCI Express x16
expansion slot.
To remove, replace, or add an expansion card:
1. Prepare the computer for disassembly (
Preparation for Disassembly on page 42).
2. Remove the access panel (
Access Panel on page 43).
3. Locate the correct vacant expansion socket on the system board and the corresponding
expansion slot on the back of the computer chassis.
Expansion Cards 55
