4. Lift the top of the keyboard upward (1), and then lift the keyboard up at an angle (2) to disengage the
tabs at the bottom of the keyboard.
NOTE: A cable (or cables) connect the bottom of the keyboard to the system board. Make sure not to
prematurely pull the cables out of the system board connector.
5. Rotate the keyboard until it rests on the palm rest (1).
6. Disconnect the keyboard cable by lifting the connector latch (2), and then disconnect the keyboard cable
from the system board (3).
46 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
