Item Description Spare part number
(1) Display panel assembly, touch screen
NOTE: Touch displays are spared only as whole assemblies.
Non-touch displays are spared only at the subcomponent level. Non-touch assemblies are not
spared as whole units.
For use in models without WWAN L01073-001
For use in models with WWAN L01074-001
(2) Keyboard (includes cable)
NOTE: For a detailed list of keyboard country codes, see Keyboard on page 44.
No backlight L01072-xxx
Backlit L01071-xxx
(3) Power button board L01044-001
(4) Top cover L01055-001
(5) TouchPad L01056-001
(6) Speaker assembly L01053-001
(7) Fingerprint reader assembly (includes cable) L01058-001
(8) Card reader board L01045-001
(9) Battery, Li-ion (4-cell, 48 WHr, 4.21 Ah) 851610-855
(10) USB board L01043-001
(11) Fan L01054-001
(12) RTC battery 746439-001
(13) System board (includes replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
Intel Core i7-8550U processor L01042-xxx
Intel Core i5-8350U processor L01041-xxx
Intel Core i5-8350U processor (vPro) L08492-xxx
Intel Core i5-8250U processor (WWAN models) L01040-xxx
Intel Core i5-8250U processor L01039-xxx
Intel Core i5-7200U processor L05788-xxx
Intel Core i3-7100U processor (WWAN models) L01038-xxx
Intel Core i3-7100U processor L01037-xxx
Intel Core i3-6006U processor L01036-xxx
Intel Celeron 3865U processor L01035-xxx
(14) Heat sink (includes replacement thermal material) L01052-001
Computer major components 19
