4. Remove the speakers from the top cover (3).
IMPORTANT: When removing the speakers, make sure the rubber feet (4) and rubber screw gaskets (5)
remain attached to the speakers. These parts must be installed with the speakers.
Reverse this procedure to install the speaker assembly.
56 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
