6. Pull the plastic tab on the hard drive (2) towards the side of the computer to disengage the hard
drive from the connector, and then lift the hard drive out of the hard drive bay.
NOTE: Refer to the illustration that most closely matches your computer. Some hard drives
may be wrapped in a plastic covering. After removing the hard drive from the computer, you
must remove the plastic covering to access the hard drive itself.
Replacing or upgrading the hard drive 39
