HP 90W Smart AC Adapter
Dimensions
5.00 x 1.97 x 1.1 in (12.7 x 5.0 x 2.9 cm)
Weight
0.82 lb (370 g)
Input
100 to 240 VAC
Input Efficiency
87% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.5 A at 90 VAC, 0.75 A at 180 VAC PFC Version
2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC Version
Output
Output power
90W
DC output
19.0V
Hold-up time
5 msec at 115 VAC input
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF- over 200,000 hours at 25°C ambient condition.
Optional HP BB09 Ultra
Extended Life Notebook
Battery
Dimensions
(H x W x L)
1.2 x 5.9 x 11.4 in (3x15x29cm)
Weight
(max)
1.5lb, (.682kg)
Cells/Type
Lithium-Ion
Energy
Voltage
11.25V
Amp-hour capacity
8.85Ah
Watt-hour capacity
100Wh
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 122° F(-10° to 50° C)
Non-operating
-4° to 122° F (-20° to 50° C)
Battery Re-Charge Time
System in OFF or Standby
Mode
3.5 to 5 hours
System ON
4 to 7 hours
Fuel Gauge LED
Yes
Warranty
1 year
Optional Travel Battery
Available
NA
QuickSpecs
HP ProBook 6465b Notebook PC
HP ProBook 6565b Notebook PC
Technical Specifications
DA - 14043 North America — Version 11 — August 2, 2012
Page 20
