Item Description Spare part number
(1) Display panel assembly, 35.6-cm (14.0-inch)
Touch displays are only spared as entire hinge-ups; touch displays are not spared at the
subcomponent level.
Non-touch displays are ONLY spared at the subcomponent level. For more information about
display components, see Display components on page 23.
Includes 1 antenna 828421-001
Includes 2 antennas 830957-001
(2) Keyboard (includes cable)
NOTE: For a detailed list of keyboard country codes, see Keyboard on page 48.
No backlight 827028-xxx
Backlit 827029-xxx
(3) Top cover (includes touchpad assembly) 828402-001
(4) Card reader board 828416-001
(5) Power button board 827035-001
(6) Function board 828419-001
(7) USB/audio board 827032-001
(8) Fingerprint reader assembly (includes cable and bracket) 828417-001
(9) Speaker assembly 828420-001
(10) RTC battery 826388-001
(11) Power connector cable 827039-001
(12) System board (includes replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-601: Windows 8.1 or Windows 10 operating system
Models with discrete graphics:
●
Intel Core i7-6500U processor; 2-GB discrete graphics memory 827026-xxx
●
Intel Core i5-6200U processor; 2-GB discrete graphics memory 827025-xxx
●
Intel Core i5-6200U processor; 1-GB discrete graphics memory 827023-xxx
●
Intel Core i3-6100U processor; 2-GB discrete graphics memory 827024-xxx
●
Intel Core i3-6100U processor; 1-GB discrete graphics memory 827022-xxx
Models with UMA graphics:
●
Intel Core i7-6500U processor (models with WWAN) 830956-xxx
●
Intel Core i7-6500U processor (models without WWAN) 830932-xxx
●
Intel Core i5-6200U processor (models with WWAN) 830955-xxx
●
Intel Core i5-6200U processor (models without WWAN) 830931-xxx
20 Chapter 3 Illustrated parts catalog
