HP ProBook 5220m - Notebook PC

Display assembly
Description Spare part number
Display assembly (includes 2 WLAN antennas and cables and, on select computer models, 2 WWAN antennas and cables)
●
WXGA AntiGlare display assembly without webcam
610807-001
●
WXGA AntiGlare display assembly with webcam
610808-001
●
WXGA AntiGlare display assembly with webcam and WWAN
610809-001
●
WXGA BrightView display assembly without webcam
610810-001
●
WXGA BrightView display assembly with webcam
610811-001
Display bezel
●
For use with displays with webcam
610814-001
●
For use with displays without webcam
610815-001
Webcam module 610835-001
Display panel
Display Hinge Kit
●
Display Hinge Kit (includes left and right display hinges)
610817-001
Display cable
●
Display cable for use with displays with webcam (includes microphone and webcam connector)
610816-001
●
Display cable for use with displays without webcam (includes microphone)
614742-001
WLAN antennas and cables (included with display back cover)
WWAN antennas and cables (included with display back cover used with WWAN option)
Display back cover
●
For use with displays without WWAN
610812-001
●
For use with displays with WWAN 610813-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 40).
5. Remove the following components:
a. Switch cover (see
Switch cover on page 51)
b. Keyboard (see
Keyboard on page 53)
Component replacement procedures 59
