HP ProBook 6450b Quickspecs

At A Glance
Genuine Windows 7 versions or FreeDOS
New Intel vPro Technology for remote manageability
Choice of Intel® Core™ i7, Core i5, or Core i3 processor
ATI Mobility Radeon HD 540v discrete graphics with 512 MB dedicated video memory
or integrated Intel HD Graphics
Widescreen LED-backlit HD or HD+ display
HP ProBook 6450b: 14.0-inch diagonal; HD anti-glare
HP ProBook 6550b: 15.6-inch diagonal; HD anti-glare or HD+ anti-glare
Starting at 5.0 lb/2.26 kg (6450b) or 5.5 lb/2.51 kg (6550b)
Flexible wireless connectivity options:
Integrated HP un2420 EV-DO/HSPA Mobile Broadband Module provides worldwide Gobi mobile Internet technology with
GPS
Integrated Intel Centrino® 802.11 a/b/g/n or b/g/n; Broadcom 802.11 a/b/g/n wireless LAN module
Bluetooth® v2.1+EDR
Touchpad with scroll zone; optional pointstick
Full-sized spill-resistant keyboard with drains; full separate numeric keypad on the HP ProBook 6550b
Touch-sensitive controls for HP QuickLook 3, HP QuickWeb, wireless on/off, mute, volume down, volume up; calculator button
on HP ProBook 6550b
Choice of 9-cell (93 WHr) or 6-cell (55 WHr & 47 WHr) primary battery, or 6-cell (51 WHr) HP Long Life Battery
3-cell (47 WHr) HP Long Life Battery available as after-market option
Optional external batteries: HP Ultra-Capacity Battery, HP Extended Life Battery
Optional integrated 2 MP Webcam with dual-microphone array
Choice of 7200 rpm user-removable hard drive up to 320 GB with HP 3D DriveGuard protection,
or 128 GB Solid State Drive
Upgrade Bay for optical drive
Media Card Reader
New eSATA/USB 2.0 combo port
Reliability with HP 3D DriveGuard, magnesium alloy support structure, HP DuraFinish, and the spill-resistant keyboard with
drains
Security features including HP ProtectTools with Central Management, Computrace LoJack Pro ready, HP SpareKey, HP Disk
Sanitizer, TPM 1.2; * optional Smart Card Reader (replaces ExpressCard slot), optional HP Fingerprint Sensor, and optional HP
Privacy Filter
HP Power Assistant allows you to conserve power, stretch battery run-time, accurately monitor your reported power need, and
report workforce power consumption.
HP QuickLook 3 for instant access to e-mail, calendar, and contacts; HP QuickWeb for fast access to the web
HP DayStarter displays your calendar and battery charge while Windows starts up
HP Support Assistant helps maintain your PC performance and resolve problems with automated updates and tune-ups,
onboard diagnostics, and guided assistance.
Options include HP Advanced Docking Station, HP Docking Station, HP USB 2.0 Docking Station, and HP Essential USB 2.0 Port
Replicator
BFR/PVC-free ** , ENERGY STAR qualified and EPEAT Gold registered in the U.S. EPEAT status varies by country- please see
epeat.net .
* TPM module disabled where not permitted by law (for example, Russia and China).
** This notebook is brominated flame retardant and polyvinyl chloride-free (BFR/PVC-free) on notebooks that are non-WWAN; meeting
the evolving definition of 'BFR/PVC-free' as set forth in the "iNEMI Position Statement on the 'Definition of Low-Halogen' Electronics
(BFR/CFR/PVC-Free)'". Plastic parts contain < 1000 ppm (0.1%) of bromine [if the Br source is from BFRs] and < 1000 ppm (0.1%) of
chlorine [if the Cl source is from CFRs or PVC or PVC copolymers]. Power supply and power cords are not BFR/PVC-free. Service parts
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Overview
DA - 13616 Canada — Version 17 — February 15, 2012 Page 5

HP ProBook 6450b Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	2 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	L2
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM57 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE802.3, IEEE802.3u, IEEE802.3ab
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Pointing device	Touchpad
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Operating system architecture	32-bit
ExpressCard slot	-
Charging port type	DC-in jack
USB 2.0 ports quantity	3
CardBus PCMCIA slots quantity	0
AC adapter power	65 W
Battery capacity	55 Wh
Number of battery cells	6
Storage relative humidity (H-H)	5 - 95 %
Product color	Black, Silver
Country of origin	China
Discrete graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	236.2 mm
Width	339 mm
Height	33.8 mm
Weight	2260 g
