Removal and replacement procedures
Maintenance and Service Guide 4–11
Mass storage device
✎
The mass storage device spare part kit includes a bracket.
Before removing the mass storage device, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-7).
Remove the mass storage device:
1. Position the computer with the front toward you.
Description Spare part number
Hard drive:
■ 500-GB, 7200-rpm 583246-001
■ 500-GB, 7200-rpm for use only with HP Compaq 6545b and 6445b models 614952-001
■ 500-GB, 7200-rpm for use only with HP Compaq 6540b and 6440b models 614953-001
■ 320-GB, 7200-rpm for use only with HP Compaq 6540b and 6440b models 615595-001
■ 250-GB, 7200-rpm 583244-001
■ 160-GB, 7200-rpm 583243-001
Solid-state drive (includes bracket):
■ 160-GB, 2.5-in solid-state drive—for use only with HP Compaq 6540b and 6440b models 598089-001
■ 128-GB, 2.5-in solid-state drive—for use with all models 583247-001
