HP ProBook 6570b Quickspecs

At A Glance
Windows 8 versions, Windows 7 versions, SuSE Linux Enterprise Desktop 11, or FreeDOS
Bead-blast aluminum display enclosure, magnesium support structure, wear-resistant
tungsten-colored HP DuraFinish, HP DisplaySafe frame, precision latches, and keyboard in full aluminum deck
Choice of 3rd generation Intel® Core™ i7 and i5 dual-core processors and 2nd generation Intel® Core i3 dual-core processor, or
Celeron® processor
Intel Core i7 with vPro™ and Core i5 with vPro technology (optional)
AMD Radeon™ HD 7570M discrete graphics with 1 GB dedicated GDDR5 video memory,
integrated Intel HD Graphics 4000 (on Intel Core i7 and i5 configurations), integrated Intel HD Graphics 3000 (on 2nd generation
Intel Core i3 configurations), or Intel HD Graphics (on Celeron configurations)
Widescreen LED-backlit display
HP ProBook 6470b: 14.0-inch diagonal HD or HD+
HP ProBook 6570b: 15.6-inch diagonal HD or HD+ WVA
Easily hot dock with one of the optional HP docking stations
DisplayPort for high resolution support
SRS Premium Sound optimized for high fidelity audio
Choice of primary battery to optimize run-time or weight: 9-cell (100 WHr), 6-cell (55 WHr), 6-cell (55 WHr) HP Long Life Battery,
or 3-cell (31 WHr)
Combine primary battery with optional secondary battery options
Touchpad with scroll zone; optional pointstick; 6570b features a numeric keypad and calculator button
Choice of standard ExpressCard slot or optional integrated Smart Card Reader for strong security authentication Security
features including HP Client Security (Windows 8 only), HP ProtectTools, with central management across HP and non-HP client
PCs
HP Peak Power Manager* (web download) and HP Power Assistant (Windows 7 only) allow you to conserve power, stretch
battery run-time, accurately monitor your reported power needs, and report workforce power consumption.
Flexible wireless connectivity options:
Optional integrated HP hs2350 HSPA+ Mobile Broadband Module connects to both HSPA and HSPA+ (UMTS) networks and
provides GPS functionality
Optional integrated HP un2430 EV-DO/HSPA Mobile Broadband Module (Gobi 3000) (provides GPS functionality)
Optional Integrated Intel Centrino® 802.11 a/b/g/n 2x2 or b/g/n 2x2, Broadcom 802.11 a/b/g/n 2x2, or Atheros b/g/n 1x1
wireless LAN module
Bluetooth® v4.0+ EDR
Upgrade Bay for optical drive, optional second hard drive, or weight saver
Choice of 7200 rpm user-removable hard drive (up to 750 GB) with HP 3D DriveGuard, 500 GB 7200 rpm Self Encrypting Drive, or
128 GB Solid State Drive
BFR/PVC-free**, ENERGY STAR qualified (with Microsoft OS) and EPEAT Gold registered in the U.S. (with Microsoft OS). EPEAT
status varies by country- please see epeat.net.
* HP Peak Power Manager replaces HP Power Assistant for both Win7 and Win8. HP Peak Power Manager will be available on the web
for download for existing product owners.
** Meeting the industry definition of 'BFR/PVC-free' per the iNEMI Position Statement on "Low Halogen" Electronics. Plastic parts
incorporated into the chassis generally contain < 1000 ppm (0.1%) of bromine or chlorine. Printed circuit board and substrate
laminates generally contain < 1500 ppm (0.15%) of total bromine and chlorine. Service parts after purchase may not be BFR/PVC-free.
External accessories, including power supplies, power cords, and peripherals as well as the following customer-configurable internal
components: ATT SIM card are not BFR/PVC-free.
QuickSpecs
HP ProBook 6470b Notebook PC
HP ProBook 6570b Notebook PC
Overview
DA - 14308 Worldwide — Version 8 — January 31, 2013 Page 5

HP ProBook 6570b Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	90 °C
Processor cache	3 MB
Processor cores	2
Processor model	i3-3110M
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-3100 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	24
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM76 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
HDD speed	7200 RPM
HDD interface	SATA II
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
LightScribe	-
Intel segment tagging	Enterprise
Ethernet interface type	Gigabit Ethernet
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Form factor	Clamshell
Product color	Black
Country of origin	China
Battery capacity	55 Wh
Battery life (max)	7.25 h
Number of battery cells	6
AC adapter power	65 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Processor code	SR0N2
Processor ARK ID	65700
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	251 mm
Width	374 mm
Height	34 mm
Weight	2510 g
