HP ProCurve 1410-24G

4
Wall Mounting Template for HP ProCurve 1410-24G Switch
Screw-hole position for
mounting
83.95 mm
3.31 Inch
150.00 mm
5.91 inch
(Under-table mounting) After installation, prevent switch
movement by placing a third screw along this side.
