HP ProCurve Switch 2510 Series
Specifications
HP ProCurve Switch 2510-24 (J9019B) HP ProCurve Switch 2510-48 (J9020A)
Ports
24 RJ-45 auto-sensing 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u
Type 100Base-TX); Media Type: Auto-MDIX; Duplex: half or full
2 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type
100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an open mini-GBIC
slot (for use with mini-GBIC transceivers)
1 RJ-45 serial console port
48 RJ-45 auto-sensing 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u
Type 100Base-TX); Media Type: Auto-MDIX; Duplex: half or full
2 RJ-45 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE
802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Media Type:
Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only
2 open mini-GBIC (SFP) slots
1 RJ-45 serial console port
Physical characteristics
Dimensions
9.3(d) x 17.42(w) x 1.73(h) in. (23.62 x 44.25 x 4.39 cm) (1U height) 9.3(d) x 17.42(w) x 1.73(h) in. (23.62 x 44.25 x 4.39 cm) (1U height)
Weight
4.89 lb. (2.22 kg), Fully loaded 6.05 lb. (2.74 kg), Fully loaded
Memory and processor
Processor
MIPS 32 @ 264 MHz, 8 MB flash, 64 MB SDRAM; packet buffer size: 384 KB MIPS 32 @ 300 MHz, 16 MB flash, 128 MB SDRAM; packet buffer size: 512
KB
Mounting
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware
included); horizontal surface mounting only
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware
included); horizontal surface mounting only
Performance
100 Mb Latency
< 4.9 µs (64-byte packets) < 4.9 µs (64-byte packets)
1000 Mb Latency
< 2.6 µs (64-byte packets) < 2.9 µs (64-byte packets)
Throughput
up to 6.5 million pps (64-byte packets) up to 13 million pps (64-byte packets)
Switching capacity
8.8 Gbps 17.6 Gbps
MAC address table size
8,000 entries 8,000 entries
Environment
Operating temperature
32ºF to 113ºF (0ºC to 45ºC) 32ºF to 113ºF (0ºC to 45ºC)
Operating relative humidity
15% to 95% @ 104ºF (40ºC), non-condensing 15% to 95% @ 104ºF (40ºC), non-condensing
Non-operating/Storage temperature
-40ºF to 158ºF (-40ºC to 70ºC) -40ºF to 158ºF (-40ºC to 70ºC)
Non-operating/Storage relative humidity
15% to 95% @ 149ºF (65ºC), non-condensing 15% to 90% @ 149ºF (65ºC), non-condensing
Altitude
up to 10,000 ft. (3 km) up to 15,000 ft. (4.6 km)
Acoustic
Power: 0 dB no fan Power: 43.6 dB; DIN 45635T.19 per ISO 7779
Electrical characteristics
Maximum heat dissipation
68 BTU/hr (71.74 kJ/hr) 92 BTU/hr (97 kJ/hr)
Voltage
100-127 / 200-240 VAC 100-127 / 200-240 VAC
Current
0.7 / 0.4 A 1.2 / 0.7 A
Maximum power rating
20 W 27 W
Frequency
50 / 60 Hz 50 / 60 Hz
Notes
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with fully
loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules
populated.
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with fully
loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules
populated.
Safety
cUL (CSA 22.2 No. 60950); UL 60950-1; IEC 60950; EN 60950 cUL (CSA 22.2 No. 60950); UL 60950-1; IEC 60950; EN 60950
Emissions
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; IEC/EN
61000-3-2; IEC/EN 61000-3-3
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; IEC/EN
61000-3-2; IEC/EN 61000-3-3
Immunity
Generic
EN 55024, CISPR 24 EN 55024, CISPR 24
ESD
IEC 61000-4-2 IEC 61000-4-2
Radiated
IEC 61000-4-3 IEC 61000-4-3
EFT/Burst
IEC 61000-4-4 IEC 61000-4-4
Surge
IEC 61000-4-5 IEC 61000-4-5
Conducted
IEC 61000-4-6 IEC 61000-4-6
Power frequency magnetic field
IEC 61000-4-8 IEC 61000-4-8
Voltage dips and interruptions
IEC 61000-4-11 IEC 61000-4-11
Harmonics
EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3
Management
HP ProCurve Manager Plus; HP ProCurve Manager; command-line interface;
Web browser; out-of-band management
HP ProCurve Manager Plus; HP ProCurve Manager; command-line interface;
Web browser; out-of-band management
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
