HP ProDesk 405 G1 - Page 3

Figure3 Rotate the top of the panel away to remove it
Figure4 Pull the 3 hooks and rotate to remove the front
bezel
Figure5 Disconnect the cooler cable from MB
Figure6 Loose 4 screws from cooler and remove it
